Compressed air system ready for delivery
Kaeser's Air System Enclosures, with flows from 224 to 2646 cfm, are complete compressed air systems delivered ready to operate in a secure, weatherproof enclosure. Each is designed for exceptional reliability, simple maintenance, and superior energy efficiency. They eliminate space, weather, and accessibility constraints and greatly reduce construction and installation time. Kaeser Air System Enclosures are a financially viable alternative to new construction or building renovations, and are built for the most challenging installation environments.
If one of these configurations below doesn't meet your needs, we can design one to your specifications and then build it, deliver it, and commission faster than you can secure a building permit.
Full walk-in design, rated for 110 mph wind loads, 50 lbs/sq. ft. snow load, fully insulated with sound dampening paneling, two entry doors (minimum), removable access panels for major service.
External power disconnect, main power distribution panel, step-down transformer, low voltage panel board, EMT conduit, individual isolation devices per equipment requirement, wiring per NEC.
Thermostatically controlled intake and re-circulation dampers, galvanized and insulated duct work, digital temperature controllers, exhaust gravity dampers.
SmartPipe or equivalent, isolation valves at critical points, external connection point.
Vibration isolation on compressor discharge piping; all compressor include machine mounting feet.
-4°F to +100°F and relative humidity <80%
